Upgraded to Roller 6.1.1

A note about this site: I just upgraded rollerweblogger.org to run the recently released Roller 6.1.1, and Java 17. There was one snag. This site uses the Roller-JSPWiki plugin and old Lucene dependency in that plugin prevented Tomcat from loading Roller. It took me a couple of hours to figure out how to upgrade the plugin to use the latest version of JSPWiki. That fixed it.


Building an Open Source J2EE Weblogger

I wrote this article for O'Reilly's OnJava.com over twenty years ago and it was published on April 17, 2002. Roller would not become Apache Roller until about five years later. Publishing this article changed my life and set my career on a new trajectory. I can't find it online anymore so to celebrate this anniversay, i'm going to publish it here on Roller.

As a Java developer, you should be aware of the tremendous wealth of open source development software that is available for your use -- even if you have no desire to release any of your own software as open source. In this article, I will introduce you to some of the most useful open source Java development tools by showing you how I used these tools to develop a complete database-driven Web application called Roller.

Roller fits into the relatively new category of software called webloggers: applications that make it easy for you to maintain a weblog, also known as a blog -- a public diary where you link to recent reading on the Web and comment on items of interest to you.

The Roller Web application allows you to maintain a Web site that consists of a weblog, an organized collection of favorite Web bookmarks, and a collection of favorite news feeds. You can define Web pages to display your weblog, bookmarks, and news feeds. By editing the HTML templates that define these pages, you have almost total control over the layout and appearance of these pages. Most importantly, you can do all of this without leaving the Roller Web application -- no programming is required.

I used over a dozen open source development tools to develop Roller, the most useful of which are listed in Table 1; however, this article focuses on just four tools: the XDoclet code generator, the Castor persistence framework, the Struts Servlet/JSP framework, and the Velocity code-generation engine. In this article I will describe the Roller application, its architecture, and specifically how I used XDoclet, Castor, Struts, and Velocity in its development.

Table 1: Open source tools used in Roller Development

Name

Description

Developer

Type of License*

Castor

Persistence framework

Exolab

Similar to BSD license

HSQL

Small but powerful Java database

Thomas Meuller

Similar to BSD license

Jakarta Ant

XML-driven Java build system

Apache

Apache Public License

Jakarta Commons

Collections, utilities

Apache

Apache Public License

Jakarta Struts

Servlet/JSP framework

Apache

Apache Public License

Jakarta Tomcat

Servlet/JSP Server

Apache

Apache Public License

Jakarta Velocity

Template-driven code generator

Apache

Apache Public License

Netbeans

Integrated Dev. Environment



Sun Public License

Xerces

XML parser

Apache

Apache Public License

XDoclet

Code generator

Dreambean

Similar to MIT License

* For more information on open source licenses see opensource.org

The Roller Application

Roller does not support all of the features of commercial weblogging software (such as Userland's Radio or Pyra Labs' Blogger products), but Roller does support what I consider the essential weblogging features. With Roller you can:

  • Maintain a weblog, with user-defined categories. You can write new weblog entries and edit entries that have already been posted. You can define a set of weblog categories and can assign weblog entries to different categories. This allows you to maintain several different weblogs, each covering a different topic.

  • Publish your weblog as an RSS news feed. Roller makes your weblog available as a standard Rich Site Summary (RSS) news feed so that readers can subscribe to and read your weblog without visiting your Roller site.

  • Maintain a collection of favorite bookmarks, organized by bookmark folders. You can define new bookmark folders and can add, delete, and edit the bookmarks within these folders. You can then display these bookmarks on one or more of your Roller site's pages. This allows you to do blogrolling -- displaying links to your favorite weblogs.

  • Maintain a collection of favorite RSS news feeds. This allows you to display headlines with links to news stories from your favorite news sources or weblogs.

  • Define a set of Web pages to display your weblog, bookmarks, and news feeds. Pages are defined using HTML templates with embedded macros for each type of data. For example, there is a $Bookmarks macro that will draw a portion of your bookmark collection on a Web page and a $WeblogCalendar macro that will draw a calendar view of your past weblog entries. These templates allow you almost complete control over the layout and look-and-feel of your Web pages.

There are two types of Roller users: readers and editors. Readers are simply anonymous visitors to the Roller Web site. Editors have user accounts and must log in by providing a user name and password. Editors have the ability to edit their weblog entries, bookmarks, newsfeeds, and page templates.

Figure 1 illustrates the Roller application by showing the Roller Web page navigation tree. The boxes represent Web pages and the arrows represent links between pages. The gray pages are the public pages that any visitor may access, the yellow pages are the login pages, and the red pages are the pages that only editors can access.

Diagram.
Figure 1: Roller Web Pages

Roller Architecture

Internally, Roller is divided into a presentation tier and a business tier, as recommended in Sun's J2EE Pattern Catalog. The presentation tier is responsible for Roller's user interface, and the business tier is responsible for Roller's application logic and the persistence of application data. Figure 2 provides an overview of the Roller architecture.

Diagram.
Figure 2: Roller Architecture

The presentation tier is implemented using the Model-View-Controller (MVC) pattern and the Struts MVC framework. The Model is an abstraction of the application logic and application data and is represented by a set of interfaces defined in the org.roller.model package. The View is implemented using Servlets, JSP pages, and Velocity page templates. The Controller is Struts, which is responsible for receiving incoming requests and dispatching them to the View. The implementation of the presentation tier is further discussed in the sections on Struts and Velocity.

The business tier implements the interfaces in the org.roller.model package, using the Castor JDO persistence framework. The business tier exchanges data with the presentation tier in the form of simple, lightweight JavaBeans known as Value Objects. Value Objects are yet another of the Sun J2EE patterns. Each Value Object maps to a table in the Roller database.

Figure 3 shows the Roller Value Objects, their properties, and the relationships between them. Each editor is represented by a User object. Each User has a Website object, which represents the editor's Web site and which has weblog entries, bookmark folders, newsfeeds, and page templates. The Website object also specifies the default page template of the Web site and which page template is used for rendering a day of weblog entries.

Diagram.
Figure 3: Roller Value Objects

The business tier uses Castor JDO to store and retrieve Value Objects to and from a JDBC-accessible database. Castor JDO is part of the larger Castor data-binding framework, which according to the Castor Web site is "the shortest path between Java objects, XML documents, SQL databases, and LDAP."

As a persistence framework, Castor JDO is similar to commercial object-relational mappers such as TopLink and Cocobase. Castor JDO fulfills a role similar to that of Sun's Java Data Objects, but Castor JDO is not an implementation of Sun's JDO specification (JSR-000012). Castor JDO allows you to define a mapping between Java classes and tables in a relational database. You can then issue queries using Castor's own Object Query Language (OQL) and receive the results as collections of Java objects.

Before you can use Castor JDO, you must provide a mapping file -- an XML file that maps each class to a database table and each class property to a field within a database table. Below is a portion of Roller's mapping file.

<mapping>
<class name=org.roller.model.BookmarkData" identity="id"
    access="shared" key-generator="UUID" auto-complete="false">
    <map-to table="bookmark"/>
    <cache-type type="count-limited"/>
    <field name="folderId" type="java.lang.String"></field>
    <field name="id" type="java.lang.String"></field>
    <field name="image" type="java.lang.String"></field>
    <field name="name" type="java.lang.String"></field>
    <field name="priority" type="java.lang.Integer"></field>
    <field name="url" type="java.lang.String"></field>
</class>
...
</mapping>

Once you provide Castor with a mapping file, retrieving a collection of objects from the database can be as simple as the code snippet shown below:

// Construct a new query and bind its parameters
String query = "SELECT p FROM BookmarkData p WHERE websiteId=$";
OQLQuery oql = db.getOQLQuery( query );
oql.bind( websiteId );

// Retrieve results and print each one
QueryResults results = oql.execute();
while ( results.hasMore() ) {
   BookmarkData bookmark = (BookmarkData)results.next();
   System.out.println( bookmark.toString() );
}

XDoclet

XDoclet is a code generator that is implemented as a Javadoc extension, a Doclet. To use XDoclet, you place special Javadoc tags in your Java source code. Based on these tags, XDoclet can generate additional Java code that supports your classes, mapping files that map your classes to database tables, and deployment descriptors that assist in deploying your classes.

XDoclet started out its life as EJBDoclet, a tool that allows you to implement an Enterprise JavaBean by writing just one source code file. Now, the XDoclet product includes two Doclets: EJBDoclet and WebDoclet. EJBDoclet is for generating EJB classes, value objects, and database mappings. WebDoclet is for generating all sorts of Servlet Web Application deployment descriptors, including web.xml files, Tag Library Descriptors, and Struts configuration files.

The Roller build process uses both EJBDoclet and WebDoclet, as shown in Figure 4. In Step 1, EJBDoclet is used to process a set of abstract classes of type javax.ejb.EntityBean -- one for each one of the Roller Value Objects. From these classes, EJBDoclet generates a Castor mapping file, the Roller Value Object classes, and a set of corresponding Struts form classes. In Step 2, WebDoclet is used to process a source directory that contains JSP tags, Servlet classes, and Struts classes. The output of the WebDoclet is the complete set of Roller Web Application deployment descriptors.

Diagram.
Figure 4: XDoclet and the Roller Build Process

Below is a simple example bean that shows the EJBDoclet tags necessary to create a Value Object. The @castor tags provide the information needed to generate the Castor mapping entries for the bean. The @ejb tags provide the information needed to generate the Value Object and a complete EJB entity bean (which Roller does not use).

/**
 * Represents a single URL in a user's favorite web-bookmarks collection.
 * @ejb:bean name="Bookmark" type="CMP" jndi-name="roller/Bookmark"
 * @ejb:data-object extends="org.roller.model.ValueObject"
 * @struts:form
 * @castor:class name="bookmark" table="bookmark" xml="bookmark"
 *               id="id" key-generator="UUID"
*/ public abstract class BookmarkBean implements EntityBean { /** @ejb:interface-method * @ejb:transaction type="Required" */ public abstract void setData(org.roller.model.BookmarkData dataHolder); /** @ejb:interface-method */ public abstract org.roller.model.BookmarkData getData(); /** @castor:field set-method="setId" * @castor:field-xml node="attribute" * @castor:field-sql name="id" sql-dirty="check" dirty="true" * @ejb:interface-method * @ejb:pk-field * @ejb:persistent-field */ public abstract String getId(); /** @ejb:pk-field * @ejb:persistent-field */ public abstract void setId( String value ); ... }

Struts

The Roller presentation tier is implemented using Struts and Velocity. Struts is a Servlet application framework that is based on the MVC pattern. In a typical Struts application, the Model is a set of JavaBeans that hold the data to be presented in the View; the View is a set of JSP pages that render HTML; and the Controller is a Servlet and set of action classes that are registered to handle incoming requests.

Roller's Edit-Bookmark form provides a nice, simple example of how Struts works. There are four parts to the Edit-Bookmark form implementation: the edit-bookmark.jsp page, the BookmarkForm JavaBean class, the BookmarkFormAction action handler, and some entries in Roller's struts-config.xml file that tie the first three items together. So, let's introduce the players:

  • The edit-bookmark.jsp page looks just like an HTML page, except that it uses the Struts HTML form tags instead of standard HTML form tags. The Struts HTML form tags know how to find the BookmarkForm JavaBean and how to use its properties to populate the form with data.

  • The BookmarkForm class is a dumb JavaBean that just holds data -- it has the exact same properties as the Bookmark Value Object. As you may recall, the BookmarkForm class and all of its sibling form classes are generated by XDoclet. In Struts, form classes must extend org.apache.struts.action.ActionForm.

  • The BookmarkFormAction is essentially an action handler. It is registered (in the struts-config.xml file) to handle incoming requests that include the pattern /bookmark.do. In Struts, action classes must extend org.apache.struts.action.Action.

Figure 5 shows the sequence of events that occurs when a request for the Edit-Bookmark form comes into the system. Roller needs to respond to this request by creating an HTML form populated with data for the bookmark that is to be edited.

Diagram.
Figure 5: Incoming request for Edit-Bookmark page

Here are the steps in processing an incoming request for the Edit-Bookmark page:

  1. The Struts Controller Servlet receives a request for the Edit-Bookmark action. The Controller uses the URI of the request to look up the FormAction that should handle the request.

  2. The Struts Controller Servlet dispatches the request to the BookmarkFormAction.edit() method. Knowing that the user has requested the Edit-Bookmark page, the BookmarkFormAction looks for a request parameter that specifies the bookmark that is to be edited.

  3. The BookmarkFormAction calls the BookmarkManager to retrieve the bookmark information that is to be edited.

  4. The BookmarkFormAction creates the BookmarkForm bean and adds that bean to the request's attributes so that it can be accessed by the JSP page.

  5. The BookmarkFormAction finally forwards the request to edit-bookmark.jsp so that the page may be rendered.

  6. The Struts form tags on the edit-bookmark.jsp page reads data from the BookmarkForm bean and uses that data to populate the Edit-Bookmark form. After that, the HTML page is returned to the user's browser for display.

Figure 6 shows the sequence of events that occurs when the request that contains posted data from the Edit-Bookmark page comes into the system. Roller needs to take the incoming form data and use it to update the bookmark that is stored in the data store managed by the business tier.

Diagram.
Figure 6: Request with data posted from Edit-Bookmark page

Here are the steps in processing a request with data from a posted Edit-Bookmark page:

  1. The Struts Controller Servlet receives a request for the Update-Bookmark action. The Struts Controller determines which action should handle the request and which form bean should receive the data from the incoming form post.

  2. The Struts Controller Servlet populates the BookmarkForm bean with data from the incoming request.

  3. The Controller calls the BookmarkFormAction and passes in the form bean.

  4. The BookmarkFormAction retrieves the data from the BookmarkForm bean.

  5. The action calls upon the BookmarkManager to store the updated bookmark information.

Velocity

While JSP pages work well for the Roller editor pages, which rarely change, JSP does not work so well for the user pages. Weblog authors are not programmers, and they cannot be required to learn JSP and Java programming just to customize their weblog and associated Web pages. Furthermore, allowing Roller users to add new JSP pages, and thus new Java code, to the Roller application at runtime is a security risk.

Screen shot.
Figure 7: Velocity-generated public page

The best solution to the user pages problem is Velocity. Velocity is a general purpose template-based code-generation engine. That may sound complicated, but from the user's point of view, it is simple and easy-to-use. For example, the weblog page shown in Figure 7 is generated by a simple Velocity template. This template is shown below:

<!DOCTYPE html PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN">
<html>
;<head>
<title>$macros.showWebsiteTitle()</title>
<style type="text/css">$macros.includePage("_css")</style>
</head>
;<body>
<table cellpadding="5" cellspacing="15"
border="0" align="center" width="95%"> <tr> <td width="20%" valign="top" bgcolor="#ffffff"> $macros.showNavBar(true)<br> $macros.showEditorNavBar(true)<br> $macros.showBookmarks("Blogrolling",true)<br> $macros.showBookmarks("News",true) </td> <td width="60%" valign="top" bgcolor="#ffffff"> <h2>$macros.showWebsiteTitle()</h2> $macros.showWeblogCategoryChooser()<br> $macros.showWeblogEntries() </td> <td valign="top" bgcolor="#ffffff" width="20%"> $macros.showWeblogCalendar()<br> $macros.showRSSBadge() </td> </tr> </table> </body> </html>

The items that start with $ are Velocity expressions, most of which result in calls to JSP tags that have been specially designed to work with Velocity. For example, the $macros.showWeblogCategoryChooser() expression results in the generation of the navigation bar at the top of the page -- the one that reads "All | Technology | News | Entertainment." The navigation bar is implemented in a custom JSP tag class named org.roller.presentation.tags.NavigationTag, which is also used in the JSP-based Roller editor pages.

Each user can define any number of pages, and since these pages are simply HTML pages, they can be customized using Front Page or any other HTML editor. The user just has to put the Velocity expressions in the right place. Below is a list of some of the Velocity expressions that are available for use in user-defined Roller Web pages.

Macro

Emits HTML for:

$macros.showNavBar()

Navigation bar, with a link to each one of the user's user-defined pages

$macros.showEditorNavBar()

Editor navigation bar, with links to the edit-bookmarks,edit-newsfeeds, edit-weblog, and edit-website pages

$macros.showBookmarks()

Entire bookmark collection in a multi-column table

$macros.showNewsfeeds()

Current headlines and story descriptions for the user's RSS newsfeeds

$macros.showWeblogEntries()

The most recent weblog entries

$macros.showWeblogCalendar()

A weblog calendar, with a link for each day on which there is a weblog entry

Conclusion

In this article, I have described four open source Java development tools and how these tools can be used together to develop a fairly sophisticated Web application. I hope I have given you a good idea of the power and flexibility of these tools.

Although I have not mentioned any problems with the open source tools that I have discussed, I did run into a number of bugs. I was able to find work-arounds and fixes for these bugs, but it was not always easy. I had to spend some time browsing mailing-lists, searching with Google, and, in one case, downloading the latest source for a product and building it myself. Formal technical support is not available for many open source tools, so keep in mind that you may have to solve your own problems.

In closing, I would like to thank the many developers and other contributors that made possible the open source Java development tools that I used in the development of Roller. The tools are great and they just keep getting better.

Resources

Weblogging

Castor

Struts

Velocity

XDoclet

Originally published here: http://onjava.com/onjava/2002/04/17/wblogosj2ee.html


Blogging about Roller 6.1

I barely even update this blog, but I do update the software that powers it and I'm happy to still have the help of an awesome team of volunteers who pitch in when they want to and always when needed. Today we released Apache Roller 6.1.0, a release we had been talking about, but that was prompted by the Log4J vulnerability. See the project's blog for details.

I'm not the one making the most code changes in Roller now days, but I do help with releases. I've been spending my spare cycles hacking on BlogQL, a Node/TypeScript-based blog server with a GraphQL API and a React front-end. It's really more of an example app to help me understand those technologies, kind of like Roller. Maybe I'll write about it someday. That's all for now.


Apache Roller 6.0.2 released!

The Roller PMC has approved the release of Apache Roller 6.0.2, a minor bug fix release.

You can download the release via Apache mirrors link here:

Roller 6.0.2 includes the fixes listed below:

Parse referrer URL instead of using string value directly

Improved: the UI for the blog entries page

Improved: tooltip content on the registration form

Updated: the main menu to have proper space when displaying permission message

Updated: the header to show the tagline only when it's available

UI fixes are thanks to new contributor Yash Maheshwari.

On behalf of the Roller PMC,
Enjoy and best regards!

Roller 6 released

This latest release of Roller includes a new UI that uses Twitter Bootstrap 3 and is based on work I started in 2015 and first committed on December 21, 2015 with this commit: 2da6c3c2e28419f68244e0c362c15be96013d5f9. You can find the details on on the Roller project blog. I got lot of help along the way with testing, fixes, dependency upgrades, Java 11 support and more, so thanks to all that helped make this happen.


Powered by Digital Ocean Kubernetes

Just a note to say that I've switched this site over to Digital Ocean Kubernetes service, which is in Limited Availability right now.

Digital Ocean's Kubernetes service is just as simple and well designed as the rest of Digital Ocean. I mentioned before that I rolled my own Kubernetes cluster via Ansible and Kubeadm. Now I can delete all those config files and that's a good thing. Plus, the price is right; I can get by with one $10/month node (1 CPU / 2 GB memory) and a $10/month load balancer.

To get this site up and running I had to deploy four things to my cluster. I installed the NGINX Ingress Controller, Cert-Manager for automatic creation of Let's Encrypt TLS certs, PostgreSQL and my custom build of Apache Roller. All of that went pretty smoothly and I didn't run into and problems that I could blame on Digital Ocean.


Roller 6.0.0-SNAPSHOT

Upgraded this site to Roller 6.0.0-SNAPSHOT today, which meant an hour of fiddling around with my private Docker registry, then giving up and using the one free private repository offered by DockerHub and then, another hour of futzing around trying to figure out my PostgreSQL JDBC driver doesn't work anymore (I inadvertently upgraded from JDK 1.7 to 1.8) and why I can't seem to upgrade it (Kubernetes caches Docker images unless you set imagePullPolicy to always). In the end, I got it working. This post is written in the yet to be officially release Apache Roller 6.0.0-SNAPSHOT version.

Side note: the new rich-text editor in Roller is now Summernote and it seems quite nice. I need to tweak it a bit because there is currently no way to set the font or add a link unless you switch to raw HTML mode.


Roller's new web UI

About three years ago I decided to modernize and improve the Apache Roller web UI by rewriting the JSP pages to use the Struts 2 Bootstrap tags, which use Twitter's Bootstrap v3 components and JavaScipt. I also wanted to replace all the HTML table-based formatting with div's and Bootstrap, do a bunch of other improvements and make Roller's web UI less clunky and annoying.

Converting Roller's eight-five JSP pages was a big task and I did not have much time for it. That's why it took three years. Ironically, the Roller modernization project leaves Roller three years out of date. Still, I think it is a huge improvement over the Roller v5 web UI and I want to get it released in Roller v6. Currently, this work is available as Pull Request #22 and you can find some screenshots there too. Here's one:

screenshot of Roller Edit Entry page

Try it with Docker-Compose

I also did some work to make it super-easy to try the Roller v6 snapshot pre-release for yourself, by using Docker Compose. You don't have to fiddle with Tomcat or PostgreSQL. You can find a simple Dockerfile for running Roller v2 snapshot and a docker-compose.yml file linked below. And you can find a Docker image in my DockerHub repo.

If you want to try Roller v6 snapshot, here's what you need to do:

1 - If you don't aleady have it, install Docker

2 - Create a directory on your computer where you want Roller to store it's data.

3 - Save this file docker-compose.yml to that new directory.

4 - Open a shell in that new directory and run:

docker-compose up

5 - Watch the PostgreSQL and Roller startup logs scroll by

6 - When the log scroll slows go to http://localhost:8080 to access Roller and go through the initial setup.

Alternatively, if you want to try Roller the hard way, you can get the regular-style v6 SNAPSHOT release files here roller/roller-6.0/v6.0.0.

Let us know how it goes

I hope you'll give Roller v6 snapshot a try and let the project know how it can be improved for your use. Send feedback to the Roller mailing lists or ttweet at us at @apache_roller.



Powered by Kubernetes

kubernetes logo Just a quick note to say that I ditched Docker Swarm and now this rarely updated blog is powered by Kubernetes. Total overkill, I know. Like Roller itself, I did it as a learning exercise. I hope to blog more about what I learned by doing this. For now, here's a quick summary of what I've done so far.

Created a cluster

I created a 2-node Kubernetes cluster on Digital Ocean using some hand-crafted Ansible scripts that call apt-get to install and kubeadm to start Kubernetes. I considered using Typhoon to create the cluster, but I really wanted to learn how to install Kubernetes "from scratch".

Ran two Ingress Controllers

To avoid using Digital Ocean's $20/month load balancer I'm running an Nginx Ingress controller on each node, and pinning containers to nodes using labels and nodeSelectors. I had to borrow Nginx Controller setup files from the Typhoon project because I'm still kind of bewildered by Ingresses.

Deployed my containers

Next, I wrote Kubernetes YAML files for deploying my containers: a private Docker Registry, PostgreSQL and my custom Roller image. Getting the private registry working properly was the biggest challenge. I need private because I don't want to make my custom Roller image public. Next, I'll install Jenkins next for CI/CD of my custom Roller build via the Jenkins Kubernetes plugin.

Let me know if there are any aspects of this that you'd like to see covered in a blog entry, or suggestions for running the cluster without two Ingress Controllers. I've already got a post cooking about installing a TLS secured Docker Registry on Kubernetes.


Powered by Postgresql and Docker Swarm

It was somewhat painful but due to some problems with MySQL and Docker, and some general uneasiness with MySQL, I switched this site from MySQL v5.7 to PostgreSQL v10. I also switched over to Docker Swarm. Here's the Docker-Compose file that I'm using now to run this site:
version: '3.2'

services:

   postgresql:
      image: "postgres:10.0"
      ports:
         - "5432:5432"
      deploy:
         resources:
           limits:
              memory: 50M
      volumes:
         - type: bind
           source: /var/lib/postgresql/data
           target: /var/lib/postgresql/data
      environment:
        - POSTGRES_USER=roller
        - POSTGRES_DB=rollerdb
        - POSTGRES_PASSWORD_FILE=/run/secrets/pg_passwd
      secrets:
        - source: db_passwd
          target: pg_passwd

   roller:
      image: "rwo:latest"
      ports:
        -  "80:8080"
      depends_on:
        - postgresql
      deploy:
         resources:
           limits:
              memory: 800M
      volumes:
        - type: bind
          source: /var/lib/roller
          target: /var/lib/roller
      environment:
        - DB_HOST=postgresql
        - STORAGE_ROOT=/var/lib/roller
        - JAVA_OPTS="-Xmx700m"

secrets:
  db_passwd:
    file: ./db_passwd.txt
It was a pain, but sometimes pain = gain and I learned a lot. I'm hoping the site will be a bit more stable now.

Modernizing the Roller UI

I don't blog very often but I still find time to work on my blog's software: Apache Roller.

Recently, I decided to focus on improving Roller's ancient Struts 2-based user interface (UI). I had considered adding a comprehensive API to Roller and building a new UI based on that API, but wow that is a huge amount of work. Instead, I decided to modernize the Roller UI by using Twitter's Bootstrap components and CSS styles.

So far, I've devoted a couple of weekends to this work and made some pretty good progress. I'm about half-way done. I'm using the Struts2-Bootstrap plugin, adding better client-side form validation with JavaScript and doing my best to improve the overall user experience. You can see an album of the pages I've done so far on Flickr:
Roller UI with Bootstrap
.

I would love any contributions, so if you are interested in helping out, please submit Pull Requests against the bootstrap-ui branch in the Apache Roller repo on GitHub.


Fractal fun with HTML5 and TypeScript

MbCanvas is a fun project that I did in 2015: a simple Mandelbrot Set viewer written in Typescript and using the HTML5 Canvas. I did the project to learn more about Typescript and the HTML5 Canvas and I must say, Typescript very nice -- so much easier to read and write than plain old JavaScript, at least for me.

Here's an example image from the viewer.

mandelbrot set image

The project is fairly easy to build if you've got Node and NPM installed, or you can play around with it here: mbcanvas - Mandelbrot viewer in TypeScript


Usergrid-Vagrant updated for Usergrid 2

GitHub logo

If you're interested in trying the not-yet-released Apache Usergrid 2 you might want to checkout my Usergrid-Vagrant project on GitHub. I just updated the project to support Usergrid 2, using the latest code from the Usergrid "release" brach. The big changes were switching to OpenJDK 8 and adding ElasticSearch. I also rewrote the scripts to use plain old Bash instead of Groovy.

https://github.com/snoopdave/usergrid-vagrant

If you want the old Usergrid 1 Vagrant-file then checkout the "1.x" branch.


Now hosted on DigitalOcean

After thirteen years of hosting this blog at Kattare.com, I've moved it over to DigitalOcean. Kattare was great, but nowadays I prefer managing my own server and DigitalOcean makes that very easy -- and costs less ($10/month vs. $26/month at Kattare).

The move was easy, or as easy as setting up OpenJDK 8, Tomcat 7 and MySQL 5.5 can be. I only hit one little snag. Once I added the Roller WAR to Tomcat, Tomcat would hang on startup. I used jstack to look at the Java VM threads and found some clues that led me to a post on ServerFault.com: Tomcat 7 hangs on deploying apps. As recommended in that post, I added -Djava.security.egd=file:/dev/./urandom to my CATALINA_OPTS and was back in action.


Apache Shiro for authentication in Roller

Shiro logo

This is the third of my 2014 side projects that I'm sharing and one that involves the Apache Roller blog server and the Apache Shiro security framework. You might find this interesting if you're considering using Shiro for authentication and authorization, or if your interested in how security works in Apache Roller.

Inspired by my work with Ember.js in Fall 2014, I started thinking about what it would take to build an Ember.js-based editor/admin interface for Apache Roller. To do that, I'd need to add a comprehensive REST API to Roller, and I'd need a way to implement secrity for the new API. I've enjoyed working with Apache Shiro, so I decided that a good first step would be to figure out how to use Apache Shiro in Roller for Roller's existing web interface.

Working over the winter break I was able to replace Roller's existing Spring security implementation with Shiro and remove all Spring dependencies from my Rollarcus fork of Roller. Below I'll describe what I had to do get Shiro working for Form-base Authentication in Roller.

Creating a Shiro Authorizing Realm

The first step in hooking Shiro into Roller is to implement a Shiro interface called ShiroAuthorizingRealm. This interface enables Shiro to do username and password checks for users when they attempt to login, and to get the user's roles.

Below is the first part of the class, which includes the doGetAuthenticationInfo() method, which returns the AuthenticationInfo for a user specified by an AuthenticationToken that includes the user's username. In other words, this method allows Shiro to look-up a user by providing a username and get back the user's (hashed) password, so that Shiro can validate a user's username and password.

ShiroAuthorizingRealm.java (link)
public class ShiroAuthorizingRealm extends AuthorizingRealm {

    public ShiroAuthorizingRealm(){
        setName("ShiroAuthorizingRealm");
        setCredentialsMatcher(
            new HashedCredentialsMatcher(Sha1Hash.ALGORITHM_NAME));
    }

    @Override
    public AuthenticationInfo doGetAuthenticationInfo(
        AuthenticationToken authToken) throws AuthenticationException {

        UsernamePasswordToken token = (UsernamePasswordToken) authToken;

        User user;
        try {
            user = loadUserByUsername( token.getUsername() );

        } catch (WebloggerException ex) {
            throw new AuthenticationException(
                "Error looking up user " + token.getUsername(), ex);
        }

        if (user != null) {
            return new SimpleAuthenticationInfo(
                user.getUserName(), user.getPassword(), getName());

        } else {
            throw new AuthenticationException(
                "Username not found: " + token.getUsername());
        }
    }

In the code above you can see how we pull the username out of the authToken provided by Shiro and we call a method, loadUserByUserName(), which uses Roller's Java API to load a Roller user object specified by name.

The next method of interest is doGetAuthorizationInfo(), which allows Shiro to look-up a user's Role. This allows Shiro to detmerine if the user is a Roller admin user or a blog editor.

ShiroAuthorizingRealm.java (continued)

    public AuthorizationInfo doGetAuthorizationInfo(
        PrincipalCollection principals) {

        String userName = (String)
            (principals.fromRealm(getName()).iterator().next());

        User user;
        try {
            user = loadUserByUsername( userName );
        } catch (WebloggerException ex) {
            throw new RuntimeException("Error looking up user " + userName, ex);
        }

        Weblogger roller = WebloggerFactory.getWeblogger();
        UserManager umgr = roller.getUserManager();

        if (user != null) {
            List roles;
            try {
                roles = umgr.getRoles(user);
            } catch (WebloggerException ex) {
                throw new RuntimeException(
                    "Error looking up roles for user " + userName, ex);
            }
            SimpleAuthorizationInfo info = new SimpleAuthorizationInfo();
            for ( String role : roles ) {
                info.addRole( role );
            }
            log.debug("Returning " + roles.size()
                + " roles for user " + userName + " roles= " + roles);
            return info;

        } else {
            throw new RuntimeException("Username not found: " + userName);
        }
    }

In the code above you can see that we use the loadUserByUsername() too look-up a user by username, then we use Roller's Java API to get the user's roles. We add those roles to an instance of the Shiro class SimpleAuthorizationInfo and return it to Shir.

Creating a Shiro Authorizing Filter

Now that we've implementated a realm, we've provided Shiro with everything needed to authenticate Roller users and get access to Roller user role information. Next, we need to configure Shiro to enforce roles for the URL apths found in Roller. Shiro includes a RolesAuthorizationFilter, which is close to what we need but not exactly right for Roller. I had to extend Shiro's roles filter so that we can allow a user who has any (not all) of the required roles for a resource.

RollerRolesAuthorizationFilter.java (link)
public class RollerRolesAuthorizationFilter
    extends RolesAuthorizationFilter {

    @Override
    public boolean isAccessAllowed(
        ServletRequest request,
        ServletResponse response,
        Object mappedValue) throws IOException {

        final Subject subject = getSubject(request, response);
        final String[] roles = (String[]) mappedValue;

        if (roles == null || roles.length == 0) {
            return true;
        }

        // user is authorized if they have ANY of the roles
        for (String role : roles) {
            if (subject.hasRole(role)) {
                return true;
            }
        }
        return false;
    }
}

Configuring Shiro for Roller

Now that we've seen the Java code needed to hook Shiro into Roller, lets look at how we configure Shiro to use that code. We do that using the Shiro configuration file: shiro.ini, as shown below.

shiro.ini (link)
[main]

defaultRealm = org.apache.roller.weblogger.auth.ShiroAuthorizingRealm
securityManager.realms = $defaultRealm

cacheManager = org.apache.shiro.cache.ehcache.EhCacheManager
securityManager.cacheManager = $cacheManager

authc = org.apache.shiro.web.filter.authc.FormAuthenticationFilter
authc.loginUrl = /roller-ui/login.rol
authc.successUrl = /roller-ui/menu.rol

rollerroles = org.apache.roller.weblogger.rest.auth.RollerRolesAuthorizationFilter

[urls]

/roller-ui/login.rol          = authc
/roller-ui/login-redirect.rol = authc, rollerroles[admin,editor]
/roller-ui/profile**          = authc, rollerroles[admin,editor]
/roller-ui/createWeblog**     = authc, rollerroles[admin,editor]
/roller-ui/menu**             = authc, rollerroles[admin,editor]
/roller-ui/authoring/**       = authc, rollerroles[admin,editor]
/roller-ui/admin/**           = authc, rollerroles[admin]
/rewrite-status/**            = authc, rollerroles[admin]
/roller-services/rest/**      = authcBasic, rollerroles[admin,editor]

In the configuration file above, you see how we hook in the new ShiroAuthorizingRealm on line 3. The next couple lines are boiler-plate code to hook in Shiro's caching mechanism and then, on line 9, we configure an authentication method called authc, which is configured to use Shiro's Form Authentication feature. And, on line 13, we hook in our new RollerRolesAuthorizationFilter.

Next, we tell Shiro that the login page for Roller is /roller-ui/login.rol and which page to direct a user to on a successful login, /roller-ui/menu.rol, if the user did not specify which page they wanted to access. And finally, on lines 17-25, you see the list of Roller URL patterns that need protection, which authentication method to use (authc or authcBasic) and the authorization filter and roles required for access to the URL pattern.

Wrapping up...

That's all there is to the story of Roller and Shiro so far. I was able to get Roller's form-based authentication working with Shiro, but I did not try to test with OpenID or LDAP, so I assume more work will be necessary to get them working. I did the work in my experimental Rollarcus fork of Roller. You can get the code from the shiro_not_spring branch. Pull requests are quite welcome as are suggestions for improvement. Please let me know if you see anything wrong in the above code.

This work may not find its way into Roller proper, but it plays a part in my the next side-project that I will share: A REST API for Roller with JAX-RS.


Usergrid and Ember.js - part 2

In part one, I explained the basics of the example Usergrid-Ember "Checkin" app, how the index page is displayed and how login is implemented. In part two, I'll explain how Ember.js can be hooked into the Usergrid REST API to store and query JSON objects.

Ember logo

Ember.js includes a feature referred to as Ember-Data, which provides a persistence interface for storing and retrieving JavaScript objects that could be stored in memory, or stored on a server and accessed via REST API.

To use Ember-Data with your REST API you've got to define an Ember-Data model and add an Ember-Data REST adapter. If your REST API differs from what Ember-Data expects then you will probably have to extend the built-in REST adapter to handle your URL pattens, and extend the built-in REST serializer to handle your JSON format. By extending Ember-Data in this way, you can use it to store and query data from Usergrid without using the Usergrid JavaScript SDK at all. Below I'll explain what I had to do to make the Checkin app's Activities collection available via Ember-Data.

Define Ember-Data models

Ember-Data expects each of your REST API collections to have a defined data model, one that extends the DS.Model class. Here's what I added for the Activities collection:

From app.js (link)

App.Activity = DS.Model.extend({
  uuid: DS.attr('string'),
  type: DS.attr('string'),
  content: DS.attr('string'),
  location: DS.attr('string'),
  created: DS.attr('date'),
  modified: DS.attr('date'),
  actor: DS.attr('string'),
  verb: DS.attr('string'),
  published: DS.attr('date'),
  metadata: DS.attr('string')
});

Create a custom RESTAdapter

The Ember-Data REST adapter expects a REST API to follow some common conventions for URL patterns and for JSON data formats. For example, if your REST API provides a collection of cats then Ember-Data will expect your REST API to work like so:

What Ember-Data expects for a cats collection:

  • GET /cats - get collection of cats
  • POST /cats - create new cat.
  • GET /cats/{cat-id} - get cat specified by ID.
  • PUT /cats/{cat-id} - update cat specified by ID.
  • DELETE /cats/{cat-id} - delete cat specified by ID.

Usergrid follows the above conventions for collections, but there are some exceptions. For example, the Usergrid Activities collection. A GET on the /activities path will return the Activities of the users that you (i.e. the currently authenticated user) follow. You don't POST new activities there, instead you post to your own Activities collection at the path /users/{your-user-id}/activities. It works like this:

Usergrid's Activities collection:

  • GET /activities - get Activities of all users that you follow.
  • POST /user/{user-id}/activities - create new Activity for user specified by ID
  • GET /user/{user-id}/activities - get Activities for one specific user.

To adapt the Activities collection to Ember-Data, I decided to create a new model called NewActivity. A NewActivity represents the data needed to create a new Activity, here's the model:

From app.js (Link)

// Must have a special model for new activity because new
// Activities must be posted to the path /{org}/{app}/users/activities,
// instead of the path /{org}/{app}/activities as Ember-Data expects.
App.NewActivity = DS.Model.extend({
  content: DS.attr('string'),
  location: DS.attr('string'),
  actor: DS.attr('string'),
  verb: DS.attr('string')
});

Then, in Checkin's custom REST adapter, I added logic to the pathForType() function to ensure that NewActivities are posted to the correct path. Here's the adapter:

From app.js (Link)

App.ApplicationAdapter = DS.RESTAdapter.extend({

  host: Usergrid.getAppUrl(),

  headers: function() {
    if ( localStorage.getItem("access_token") ) {
      return { "Authorization": "Bearer "
          + localStorage.getItem("access_token") };
    }
    return {};
  }.property().volatile(), // ensure value not cached

  pathForType: function(type) {
    var ret = Ember.String.camelize(type);
    ret = Ember.String.pluralize(ret);

    if ( ret == "newActivities" ) {
      // Must have a special logic here for new activity
      // because new Activities must be posted to the
      // path /{org}/{app}/users/activities, instead of the
      // path /{org}/{app}/activities as Ember-Data expects.
      ret = "/users/" + Usergrid.user.username + "/activities";
    }
    return ret;
  }

});

You can see a couple of other interesting things in the example above. First, there's the host field which specifies the base-URL of the REST API for the Checkin app. Next, there's the headers() function, which ensures that every request carries the access_token that was acquired during login.

Create a custom RESTSerializer

Ember-Data also has expectations about the JSON format returned by a REST API. Unfortunately, what Ember-Data expects and what Usergrid provides are quite different. The two examples below illustrate the differences:

Ember-Data vs. Usergrid JSON formats

Ember-Data expects collections like this:

{
   cats: [{
       "id": "6b2360d0",
       "name": "enzo",
       "color": "orange"
   },{
       "id": "a01dfaa0",
       "name": "bertha",
       "color": "tabby"
   }]
}






Usergrid returns collections like this:

{
   action: "get",
   path: "/cats",
   count: 2,
   entities: [{
       "uuid": "6b2360d0",
       "type": "cat",
       "name": "enzo",
       "color": "orange"
   },{
       "uuid": "a01dfaa1",
       "type": "cat",
       "name": "bertha",
       "color": "tabby"
   }]
}

Ember-Data expects individual objects like this:


{
   cat: {
       "id": "a01dfaa0",
       "name": "bertha",
       "color": "tabby"
   }
}

Usergrid returns individual objects like this:


{
   "id": "a01dfaa0",
   "type": "cat",
   "name": "bertha",
   "color": "tabby"
}

You can see two differences above. Ember-Data expects JSON objects to be returned with a "type key" which you can see above: the "cats" field in the collection and the "cat" field in the individual object. Also, Ember-Data expects an object's ID field to be named "id" but Usergrid returns it as "uuid."

The deal with these differences, the Checkin app extends Ember-Data's DS.RESTSerializer. Here's the code:

From app.js (Link)

App.ApplicationSerializer = DS.RESTSerializer.extend({

  // Extract Ember-Data array from Usergrid response
  extractArray: function(store, type, payload) {

    // Difference: Usergrid does not return wrapper object with
    // type-key. So here we grab the Usergrid Entities and stick
    // them under a type-key
    var typeKey = payload.path.substring(1);
    payload[ typeKey ] = payload.entities;

    // Difference: Usergrid returns ID in 'uuid' field, Ember-Data
    // expects 'id'. So here we add an 'id' field for each Entity,
    // with its 'uuid' value.
    for ( var i in payload.entities ) {
      if ( payload.entities[i] && payload.entities[i].uuid ) {
        payload.entities[i].id = payload.entities[i].uuid;
      }
    }
    return this._super(store, type, payload);
  },

  // Serialize Ember-Data object to Usergrid compatible JSON format
  serializeIntoHash: function( hash, type, record, options ) {

    // Usergrid does not expect a type-key
    record.eachAttribute(function( name, meta ) {
      hash[name] = record.get(name);
    });

    return hash;
  }
});

In the code above you can see how the extractArray() method moves the "entities" collection returned by Usergrid into a type-key field as expected by Ember-Data and how it copies the "uuid" field to add the "id" field that Ember-Data expects.

We also need to transform the data that Ember-Data sends to Usergrid. You can see this above in the serializeInHash() function, which ensures that when data is POSTed or PUT to Usergrid, the type key is removed because that's what Usergrid expects.

Implementing Add-Checkin

To implement Add-Checkin, I added an HTML template called "add-checkin" to Checkin's index.html file. The template displays an Add-Checkin form with two fields: one for content and one for the location. Here's what it looks like in all its modal glory:


screenshot of add-checkin page


Both fields are simple strings (someday I'd like to extend Checkin to use location information from the browser). I won't go into detail here, but it took a bit of research to figure out how to make a Bootstrap modal dialog work with Ember.js. Below you can see the add-checkin controller, which provides a save() function to save a new checkin.

From app.js (Link)

App.AddCheckinModalController = Ember.ObjectController.extend({

  actions: {

    save: function( inputs ) {

      var content = inputs.content;
      var location = inputs.location;
      var target = this.get("target");

      var activity = this.store.createRecord( "NewActivity", {
        content: content,
        location: location,
        verb: "checkin",
        actor: {
          username: Usergrid.user.username
        }
      });

      activity.save().then(
        function( success ) {
          alert("Saved");
        },
        function( error ) {
          alert("Error " + error.responseJSON.error_description);
        }
      );

    }
  }
});

In the code above you can see how easy it is to access Usergrid data via Ember-Data now that we've got our custom REST adapter and serializer in place. We create a new Activity with a call to this.store.createRecord() and to save it all we need to do is activity.save().

Time to wrap up...

To sum things up, here are some closing thoughts and observations.

  • If you are considering JavaScript MVC frameworks, then Ember.js is definitely worthy of your consideration. The documentation makes it easy to learn and the community is friendly and helpful.
  • It would be great for Usergrid to provide an Ember.js SDK that makes it really easy to build apps with Ember.js and Usergrid.
  • Ember-Data is an integral part of Ember.js, something that you need to do pretty much anything, but it is treated as a separate package with separate documentation. That is somewhat confusing for a new user.
  • Ember-Data does not include built-in form validation so if your app includes a large number of non-trivial forms, then you may prefer AngularJS over Ember.js.
  • There is a form validation plugin for Ember.js, but it requires the experimental Ember-CLI utility. I tried to use it, but Ember-CLI was unpleasnt enough that I gave up.

I appreciate any feedback you might have about this article, the Usergrid-Ember project and Apache Usergrid. If you want to see how the whole Usergrid-Ember project fits together, find it on GitHub here: Usergrid-Ember. Next up, I'll write about my experiences using Apache Shiro to replace Spring Security in Apache Roller.


Usergrid and Ember.js - part 1

The next one of my 2014 Side projects that I’d like to share is Usergrid-Ember, an experiment and attempt to learn more about Ember.js and Apache Usergrid by implementing the Checkin example from my Usergrid mobile development talk. If you're interested in either Usergrid or JavaScript web development then I hope you'll read on...

Why Ember.js?

Ember logo

Ember.js is one of the leading frameworks for building browser-based apps. It's one of many JavaScript Model View Controller (MVC) frameworks. Generally speaking, these frameworks let you define a set of routes or paths in your app, for example /index, /orders, /about, etc. and map each to some JavaScript code and HTML templates. Handling a route usually means using Ajax to grab some “model” data from a server and using a template to create an HTML “view” of the data that calls functions provided in a "controller" object.

JavaScript MVC frameworks are not simple and each has its own learning curve. Is it really worth the learning time when you can do so much with a little library like jQuery? For most projects I think the answer is yes. These frameworks force you to organize your code in a logical and consistent way, which is really important as projects grow larger, and they provide features that may save you a lot of development time.

Based on what I've seen on the net and local meet-ups, the leading frameworks these days are Ember.js and AngularJS. After I saw Yehudi Katz’s talk at All Things Open, I decided to spend some time learning Ember.js.

Getting started with Ember.js

The first thing you see when you visit the Ember.js site is a big button that says "DOWNLOAD THE STARTER KIT" and so that is where I started. The Starter Kit is a, a minimal Ember.js project with about twenty JavaScript, HTML and CSS files. It's a good way to start: small and simple.

Ember.js Starter Kit files:

screenshot of Starter Kit directory layout

Sidebar: I do hope they keep the Starter Kit around when the new Ember-CLI tool matures. Ember-CLI generates too many magic boiler-plate files and sub-directories for somebody who is trying to understand the basics of the framework. And this is an interesting point of view: Ember-CLI is Making You Stupid by Yoni Yechezkel.

Other stuff: Bower, Grunt and Bootstrap

I like to bite off more than I can chew, so I decided to use a couple of other tools. I used Bower to manage dependencies and Grunt to concatenate and minify those dependencies, and other things like launching a simple web server for development purposes. I also decided to use Bootstrap to provide various UI components needed, like a navbar and nicely styled list views.

I won't cover the details, but it was relatively easy to get Bower and Grunt working. Here are the config files in case you are interested: bower.json and Gruntfile.js. I did hit one problem: when I included Bootstrap as one of my dependencies the Glyphicons would all appear as tiny boxes, so I decided to pull Bootstrap from a CDN instead (looks like there is a fix for that now).

Defining Index Route, Model and Template

Every Ember.js app needs to define some routes. There is a default route for the "/" path which is called the index route, and you can add your own routes using the Router object. The snippet below shows what I needed to get started:

Part of app.js (link)
// create the ember app object
App = Ember.Application.create();

// define routes
App.Router.map(function() {
    this.route("login", { path: "/login" });
    this.route("logout", { path: "/logout" });
    this.route("register", { path: "/register" });
});

Ember.js will look for the JavaScript Route and Controller objects as well as the HTML template using the names above. For example: Ember.js will expect the login route to be named App.LoginRoute, the controller to be named App.LoginController and the template to be named "login."

Let's talk about the index route. When a user arrives at your app they’ll be directed to the index route. Ember.js will then look for a JavaScript object called App.IndexRoute to provide the model data and JavaScript functions needed for the index page. Here’s a partial view of the index route:

Part of app.js (link)
App.IndexRoute = Ember.Route.extend( {

    // provide model data needed for index template
    model: function() {
        if ( this.loggedIn() ) {
            return this.store.find("activity");
        }
        return [];
    }

});

The index page of the Checkin app shows the Checkin activities of the people that you follow. Above you can see how to route's model() function makes that data available to the template for display. If the user is logged in we call the store.find(“activity”) function to call the Usergrid REST API to get an array of the latest Activity objects. There is some serious Ember-Data magic going on there and I'll cover that in part two of this article.

To display the index route, Ember looks for an HTML template called “index” and will use that template to display the index page. Below is the index template. The template is a Handlebars template and the things that appear in double curly-braces are Handlebars expressions.

Part of index.html (link)

In the above template you can see a couple of {{action}} expressions that call out to JavaScript methods defined in the Checkin app. The part of the code that uses the model is in the {{#each}} loop which loops through each Activity in the model and dispays an HTML list with the the item.content and item.location of each Activity.

Here's what the above template looks like when displayed in a browser:

screenshot of checkin app index page

Implementing Login

In Checkin, login is implemented using HTML Local Storage. Once a user has successfully logged in, the app stores the username and the user's access_token in Local Storage. When user arrives at the index page, we check Local Storage to see if that user is logged in and if not, we direct them to the login route, which in turn displays the login page using the template below.

Part of index.html (link)

The LoginController provides the functions needed by the Login page itself and there are two. There is a login() function (called on line 27 above) that performs the login, and there is a register() function (called on line 31 above) that directs the user to the New User Registration page. Here's a snippet of code from the App.LoginController that provides these two functions:

Part of app.js (link)
App.LoginController = Ember.Controller.extend({

  actions: {

    login: function() {

      // login by POST to Usergrid app's /token end-point

      var loginData = {
        grant_type: "password",
        username: this.get("username"),
        password: this.get("password")
      };

      $.ajax({
        type: "POST",
        url: Usergrid.getAppUrl() + "/token",
        data: loginData,
        context: this,
        error: function( data ) {

          // login failed, show error message
          alert( data.responseJSON.error_description );
        },
        success: function( data ) {

          // store access_token in local storage
          Usergrid.user = data.user;
          localStorage.setItem("username", loginData.username );
          localStorage.setItem("access_token", data.access_token );

          // clear the form
          this.set("username", "");
          this.set("password", "");

         // call route to handle post-login transition
          this.get("target").send("onLogin");
        }
      });
    },

    register: function() {
      this.transitionToRoute("register");
    }

  }
});

The above code shows how to login to a Usergrid app using jQuery's Ajax feature. The login() function takes the username and password values from the login form, puts those in a JSON object with grant_type "password" and posts that object to the /token end-point of the Usergrid app. If that post succeeds, the response will include an access_token. We store that in Local Storage; we'll need to use it in all subsequent calls to Usergrid.

Usergrid fans will notice that I'm not using the Usergrid JavaScript SDK. That's because Ember.js provides Ember-Data, which acts as a very nice REST client and can be adapted to work with the URL structure and JSON formats of just about any REST API. I'll write about that in part two of this article.


2014 side projects

For various reasons, I've always got a couple of coding projects on the back burner, things that I hack around with on weekends and breaks. In 2014, I started four projects and learned about Ember.js, jQuery Mobile, Apache Shiro, Apache CXF and the Arquillian test framework.

I like to share my code, so I've put my code on GitHub and I'm going to write a brief post about each here on my blog. I'll provide links as I go and, of course, I welcome any criticisms and suggestions for improvement that you might have. First up: the Usergrid-Mobile project.

The Usergrid-Mobile project

ApacheCon EU logo
To be honest, Budapest was the goal of this project. In the Spring of 2014, I decided that the best chance of getting to ApacheCon EU in Budapest was to create a great "mobile development with Usergrid" talk, and to do that I needed a great example project. The resulting project shows how to create a dumbed-down Foursquare-style "checkin" app using HTML5, JavaScript, jQuery Mobile and Apache Cordova.

Luckily for me, my talk was accepted for ApacheCon EU and in November I traveled to Budapest (took some photos) and gave the talk there.

I also presented the talk at the All Things Open conference in Raleigh, NC and you can view a video of that talk, Mobile Development with Usergrid on YouTube.



You can find the code for usergrid-mobile on GitHub. I also created a Vagrant File to launch a local instance of Usergrid for demo purposes. It's called usergrid-vagrant.

That's all for now. Next up: Usergrid-Ember.


Phoenix Websites

Phoenix_Websites logo

My eldest son Alex and his friend Austin have started a website design and creation business called Phoenix Websites and, of course, I think this is a great thing. They're not yet out of high school and just getting started, but they've already landed a couple of real live customers. They've got some skills and are not afraid of hard work, so if you're a Triangle-area small business owner and you need a nice new website, check them out.

Like any new business, they need some link love so here we go: Phoenix Websites: Website design and creation services in the Raleigh-Durham Triangle-area. Follow them on twitter at @phoenixrdu


Introduction to Apache Usergrid

I travelled to Budapest, Hungary for a couple of weeks for a very nice vacation with my wife and to speak at ApacheCon EU. Here are the slides that I presented at ApacheCon EU:



(you can also view the presentation on Slideshare.)

And here is the session abstract:

Whether you are building a mobile app or a web app, Apache Usergrid (incubating) can provide you with a complete backend that supports authentication, persistence and social features like activities and followers all via a comprehensive REST API — and backed by Cassandra, giving you linear scalability. All that, and Usergrid is open source too.

This session will explain how you can use Usergrid to provide a back-end for your application. We’ll start with an overview of Usergrid features, then explore in depth how to authenticate users, store data and query data with the REST API provided by a Usergrid server. We’ll develop a simple HTML5 app and package it as a native mobile app via Apache Cordova. We'll also cover how to run Usergrid locally for development and testing.

Main | Next page »
